# Configuring the FrSky TARANIS X9D Plus 2019 RC Controller

## Binding the receiver

[https://www.youtube.com/watch?v=1IYg5mQdLVI](https://www.youtube.com/watch?v=1IYg5mQdLVI)

[https://www.youtube.com/watch?v=RH\_RuVbF2YU](https://www.youtube.com/watch?v=RH_RuVbF2YU)





## SD card content

Download the SD card content from [here](https://downloads.open-tx.org/2.3/release/sdcard/). Select the "opentx-x9d+2019" version for X9D Plus 2019.



## OpenTX software

Download the OpenTX Companion software from [here](https://www.open-tx.org/2022/04/22/opentx-2.3.15).



## Connecting to the RC controller

Power on the controller by first squeeze the two horizontal adjust slider to the center and then press the power button (as shown in image below).

<figure><img src="https://1287130752-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FvVJ0h2a4qMIhB1I8GdV8%2Fuploads%2FWFfHIeH2NgDUwHI3Nmys%2Fimage.png?alt=media&#x26;token=954d0745-2321-4960-94d8-10933055f327" alt=""><figcaption></figcaption></figure>



Connect the controller to PC with a USB-Mini cable cable.



In Zadig, set the driver of the "STM32 BOOTLOADER" device to "WinUSB"

<figure><img src="https://1287130752-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FvVJ0h2a4qMIhB1I8GdV8%2Fuploads%2FGhSsvSDQGuAMhwDpPMf4%2Fimage.png?alt=media&#x26;token=469220d6-92fe-41d2-8780-a6d5a9a81177" alt=""><figcaption></figcaption></figure>



Open OpenTX software

Go to Settings -> Settings

<figure><img src="https://1287130752-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FvVJ0h2a4qMIhB1I8GdV8%2Fuploads%2Fg351G07gkQ3bRaW2ZIJG%2Fimage.png?alt=media&#x26;token=9c4531be-10db-4da3-bdd9-b0ee5ab8e132" alt=""><figcaption></figcaption></figure>

&#x20;![](https://1287130752-files.gitbook.io/~/files/v0/b/gitbook-x-prod.appspot.com/o/spaces%2FvVJ0h2a4qMIhB1I8GdV8%2Fuploads%2Fqq8qqT1tGLQ2uLuGsk8t%2Fimage.png?alt=media\&token=011cd9d7-d037-41a2-9559-9c470bd5d80b)
